Pillow Block Bearings

High Durability | Easy Mounting | Wide Application Compatibility

Pillow block bearings, also known as plummer blocks, are mounted units used to provide support for a rotating shaft with the help of compatible bearings. These units are essential in applications requiring robust support and easy installation.

QJL pillow block series includes models such as:

- UCP Series

- UCF Series

- UCFL Series

- UCFC Series

- UCT Series

They are widely used in agricultural machinery, textile equipment, conveyors, fans, and other industrial machinery.

UCP Series

Pillow block housing with pedestal base

UCF Series

Square flange housing type

UCFL Series

Oval flange housing type

UCFC Series

Round flange housing type

UCT Series

Take-up housing for adjustable tension

UCP Series Pillow Block Bearings

The UCP series features a pedestal-style base and is the most common type of pillow block bearing. Below are some of the most commonly used models. Additional sizes are available upon request.

Model	Inch	d (mm)	A (mm)	L (mm)	J (mm)	N (mm)	N1 (mm)	H (mm)	H0 (mm)	B (mm)	A4 (mm)	Bolt	Insert No.	Housing No.	Weight (kg)	Torque N	Torque N1
UCP201-8S	1/2	12	32	126	96	32	16	13	57	11.5	27.4	M10	UC201-8S	P203S	0.6
UCP201	12	12	30.2	127	96	33	19	14	60.7	12.7	31	M10	UC201	P203	0.65
UCP204-12	3/4	20	33.3	127	96	37	16	14	63.8	12.7	45	M10	UC204-12	P204	0.65	13	19
UCP205-14	7/8	25	36.5	140	105	38	19.5	14.3	63.5	14.3	34	M10	UC205-14	P205	0.72
UCP206-18	1-1/8	30	42.9	160	124	44	19	16	85.2	15.9	38.1	M12	UC206-18	P206	1.20	17	21
UCP207-20	1-1/4	35	47.6	167	126	48	19	17.5	95	17.5	42.9	M12	UC207-20	P207	1.53	17	21
UCP208-24	1-1/2	40	51.2	180	136	52	21	18	98	19	49.2	M12	UC208-24	P208	1.88	17	23
UCP209-24	1-5/8	45	54	189	146	54	21	20	105.5	19	49.2	M12	UC209-24	P209	2.1	17	23
UCP210-30	1-7/8	48	57.2	202	159	49	22	19	112.2	19.0	51.6	M16	UC210-30	P210	2.5
UCP211-32	2	50	60.9	217	172	50	22	22	124.5	22.0	55.6	M16	UC211-32	P211	3.3
UCP212-36	2-1/4	55	66.0	235	192	56	24	22	132.5	25.4	65.1	M16	UC212-36	P212	5.5
UCP213-40	2-1/2	65	72.0	266	210	63	29	26	149.0	25.4	65.1	M20	UC213-40	P213	5.6	25	29
UCP214	2-3/4	70	79.4	266	210	72	23	29	150.2	30.2	74.6	M20	UC214	P214	6.6	25	29
UCP215	75	75	80.9	292	232	75	23	30	164.6	33.3	77.8	M20	UC215	P215	7.3
UCP217-52	3-1/4	85	85.3	310	247	85	30	32	186.0	34.1	85.7	M20	UC217-52	P217	10.8
UCP218-56	3-1/2	90	90.1	326	262	85	30	34	205.0	34.1	85.7	M22	UC218-56	P218	13.0	27	33
UCP220-64	4	100	115.0	380	305	90	36	40	225.0	42.0	108.0	M24	UC220-64	P220	16.0
